Vimek 404 DUO

Harvester and forwarder, all in one

NEW! Vimek 404 DUO unites the best of both worlds. It combines a harvester and a forwarder in one machine. Efficiency in small-scale forestry is important. The need for smart solutions and the possibility of combining different machines have high demand today. We have taken this into account in the development of Vimek 404 DUO.





Vimek 404 DUO
Technical specifications
Motor CAT C2.2T CRDI 50 kW
Transmission Hydrostatic / mechanical
Ground clearence 40 cm
Dimensions
Axle width 2,10 m
Lenght 4,65 m (loading area 3,40 m, cargo space 2,0 m²)
9,25 m incl. trailer
Width 1,80 m or2,05 m
Weight 4.700 kg, trailer excluded
Crane
Model Vimek - Mowi P25
Max. reach 5,20 m
Lifting capacity 400 kg at 5,2 m
Gripping area 0,16 m²
Harvesting unit
Model Keto Forest Supreme V3
Keto Forst Xtreme (option)
Max. diameter 300 mm
Weight 269 kg
300 kg (Xtreme)
Saw engine 10 cc
Bucking system
Models DASA H50/H70
Accessories
Clamshell bucket
Weight 130 kg
Max. opening 1300 mm
Speed 50 mm
Volume 125 liter
Technical data click here
Vimek C12 - Thinning head
Weight 160 kg
Diameter 795 mm
Rotation speed 1100 rpm
Technical data click here
